Caterpillar 3412C Fire Pump Engine

The Caterpillar 3412C fire pump engine is an V-12, 4-Stroke-Cycle-Diesel engine with a 137.0 mm (5.4 in) bore, 152.0 mm (6.0 in) stroke and 27.0 L (1648.0 in³) displacement.

The Caterpillar 3412C fire pump engine is rated at 2100 RPM and rated at 739 BHP (551 bkW).

Caterpillar 3412C fire pump engine complies with Non-Certified. Available for global non -regulated areas. Not FM Approved,Not UL Listed, air intake is turbocharged After cooling.

As part of EMAC, Caterpillar Pump also offers high performance propulsion and handling solutions Engine, engine provides electronic control and mechanical, fuel common rail system for customers to choose, we provide full life cycle service for all customers, from design to ship power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from Troubleshooting to Overhaul Technical Support.

Advantages of 3412C Fire Pump Engine

  • Package Size : Ultra-compact package size ensures ease of installation as well as exceptional power density.

  • Emissions : U.S. EPA Tier 3, Tier 2 or Non-certified emission standards for stationary emergency fire pump engines. FM Approved, UL Listed.

  • High Performance : Substantial torque rise delivers impressive performance throughout a wide speed range while maintaining lowoperating costs.

  •  Fuel Efficiency : Fuel consumption optimized to match operating cycles of a wide range of equipment and applications while maintaining low operating costs.

  • Reliable, Quiet and Durable Power : World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life.

Technical Specifications

Basic Introduction of Caterpillar 3412C Fire Pump Engine

Engine Model: 3412C
Engine Type: V-12, 4-Stroke-Cycle Diesel
Displacement: 27 L
Rated Power / Speed: 551 kW @ 2100 RPM
Aspiration Method: Turbocharged Aftercooled (TA)
Emission Standard: Non-Certified
Bore * Stroke: 137 mm (5.4 in) * 152 mm (6 in)
Packing Size(L * W * H): N/A
Weight , Net Dry: 2579 kg (5686 lb)
Lead Time: 15-30 Working Days
Payment Terms: T/T ,L/C

CAT C18-545 Land Driling Engine-788X376

coming soon

coming soon

Engine Model

Rated Power

Aspiration

Emissions

3412C 551 kW @ 2100 RPM Turbocharged-Aftercooled Non-Certified
—-END—-

General Engine Specifications of CAT 3412C Pump Drive Engine

ENGINE Configuration V-12, 4-Stroke-Cycle-Diesel Emissions Non-Certified
Bore 137 mm (5.4 in) Stroke 152 mm (6 in)
Displacement 27 L (1648 in³) Aspiration Turbocharged-Aftercooled
Governor and Protection Altronic III Oil Change Interval 750 hours
Length 2000 mm (78.7 in) Height 1413 mm (55.6 in)
Rotation Counterclockwise Flywheel Teeth 136 SAE 0
Weight 2579 kg(5686 lb)
——END——

Engine Performance Data Rated Power of CAT 3412C Pump Drive Engine

Maximum Power 551 bkW (739 BHP) Rated Speed 1750-2100 RPM
Minimum Power 476 bkW (638 BHP) Emissions Non-Certified. Available for Global Non-Regulated Areas.
Aspiration Turbocharged Aftercooled (TA)
——END——

System of Caterpillar 3412C Pump Drive Engine

Air inlet System Air Cleaner, Regular Duty with Service Indicators Exhaust System Exhaust Manifold
Turbocharged Exhaust Elbow, Dry. 203 Mm (8 in) on All Turbocharged Engines and Turbocharged Aftercooled with Wet Exhaust. 152 Mm (6 in) on Turbocharged Aftercooled with Dry Manifolds
Cooling System Thermostats and Housing Fuel System Fuel Filter
Jacket Water Pump, Centrifugal Fuel Transfer Pump
Heat Exchanger Installed Primary Fuel Filter
Expansion Tank Fuel Priming Pump
Lube System Crankcase Breather, Top Mounted instrumentation System Instrument Panel, LH
Oil Cooler Engine Oil Pressure Gauge
Oil Filler in Valve Cover and Dipstick, Both RH Fuel Pressure Gauge
Lube Oil Filter Water Temperature Gauge
Rear Sump Oil Pan Tachometer
Control System Charging Alternator 24 Volt, 35 Amp Starting System Volt, LH Electric Starting Motor
Governor Control Jacket Water Heater (6 kW, 240-480 Volt)
Hydra-Mechanical Governor
——END——

Scopes of Supply of CAT 3412C Pump Drive Engine

Air Intake System 1. Air Intake Manifold Exhuast System 1. Exhuast Manifold
2. Water-Air Intercooler 2. Turbocharger
3.Air Filter 3. Exhuast Elbow
Starting System 1. Starter Motor Charging System 1. Charging Alternator
2. Starter Rely 2. N/A
Lubricating System Fuel System
1. Electronic Fuel Transfer Pump
1. Oil Pump 2. Common Rail Fuel System
2. Oil Filter 3. Fuel Filter
4.ECU & Wiring Harness
Engine Auiliary Accessories 1.N/A Power Output System 1. Flywheel
2. N/A 2. Standard Flywheel Housing
Control System 1. ECU Socket and Sensors Engine Mounting System 1. Engine Mouting Bracket
Cooling System 1. Water Pump
2. Engine Fan
3. Standard Radiator
——END——

Optional Accessories of CAT 3412C Pump Drive Engine

Air Intake System 1. Air Intake Pre-heater Exhuast System 1. Muffler & Bellows
2. Air Intake Pre-Filter 2. Flame Trap
3. Air Filter Alarm System 3. Spark Arrestor Type Muffler & Bellows
4. Air Intake Shut-Off Valve 4. DPF System
Fuel System 1. Coarse Filter Engine Auiliary Accessories 1. Hydraulic Oil Pump
2. Fuel Pre-Heater 2. Air Compressor
Starting System 1. Manual Magnetic DC Contactor Cooling System 1. Silent Type Radiator
2. Dual Ears Flywheel Housing 2. Plateau Radiator
3. Spring Starter Motor 3. Salt-Spray Resistant Radiator
4. Air Starter Motor 4. Coolant Pre-Heater
5. Hydraulic Starter Motor 5. Jacket Water Heater
6. Extra Electric Starter Motor 6.N/A
7. Remote Starting Function 7.N/A
8. Lock Protection Function of Starter Motor 8.N/A
9. Manual Magnetic DC Contactor 9.N/A
Power Output System 1. Clutch Control System 1. Engine Monitor
2. Add Gearbox for Higher Output Speed 2. NFPA20 Standard Engine Control Box
3. N/A 3. NFPA20 Fire Fighting Pump Set Control Panel
Lubricating System 1. Oil Pre-Heater Engine Mounting System 1. Shock Absorber Pad
——END——

As part of EMAC, PumpMac focusing on water pump set related business, from pump drive engine, to WPT PTO, from complete engine power pack to complete water pump set, from NFPA20 standard fire fighting pump accessories to fire pump drive package, from explosion proof accessories to complete explosion-proof water pump set, PumpMac provides professional one-stop solution for everything customer needed for water pump set industry.
For more information of our pump drive power pack and complete water pump set products, you are welcome to visit PumpMac homepage: www.pumpmac.com

Modifiable Components of CAT 3412C Pump Drive Engine

Air Intake System 1. Installation Position of Air Filter Charging System 1. 12V Charging Alternator for 12V Electric System
2. Upgrade to Heavy-Duty Type Air Fitler 2. Explosion-Proof Charging Alternator
 3.N/A 3. Upgrading to Specified Brand and Speicifications of Charging Alternator
Exhuast System 1. Can Modify Installation Position and Direction of Turbocharger Lubricating System 1. Oil Pan Position
2. Water-Cooled Exhuast Manifold 2. Number of Dipstick
3. Water-Cooled Turbocharger 3. Position of Dipstick Can Choose From 6 Positions
4. N/A 4. Can Modify Oil Filter to Be Remote Installation
Fuel System 1. Upgrade to Fuel Fitler That Integrated with Fuel Transfer Pump and Fuel Pre-Hearter Starting System 1. 12V Starter Motor for 12v Electric System
2. N/A 2. Upgrading to Specified Brand and Speicifications of Starter Motor
Cooling System 1. Can Modify Engine Fan Into Blower Fan or Suction Fan Power Output System 1. Can Modify Size of Flywheel Housing and Flywheel
2. Can Modify Central Position of Engine Cooling Fan 2. Dual-Ear Flywheel Housing (for Twin-Starter System)
3. Can Choose Type of Engine Fan From Mechanical Type or Electric Type 3. Some of Models Can Modify Flywheel Housing Into Pto Integrated Type
4. Can Modify Cooling System Into Heat Exchanger and Intercooler 4. Engine Have Connecting Port of Ptos, That Able to Provide Power Output
Engine Shut-Down System 1. 12V Solenoid for 12V Electric System Engine Mounting System 1. Can Modify Engine Mouting Bracket
2. Explosion-Proof Solenoid
Engine Auiliary Accessories 1.N/A Control System 1. ECU Can Setting to Different Control Mode, Including Can  Communication, Analogu Control, Isc1,Isc2,Isc3 Speed Conrol Mode ETC
——END——

Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
