Caterpillar 3508 Fire Pump Engine

The Caterpillar 3508 fire pump engine is an V-8, 4-Stroke-Cycle-Diesel engine with a 170.0 mm (6.7 in) bore, 190.0 mm (7.5 in) stroke and 34.5 L (2107.0 in³) displacement.

The Caterpillar 3508 fire pump engine is rated at 1800 RPM and rated at 1000 BHP (746 bkW).

Caterpillar 3508 fire pump engine complies with non-certified and are available for global non-regulated areas, air intake is turbocharged After cooling.

As part of EMAC, Caterpillar Pump also offers high performance propulsion and handling solutions Engine, engine provides electronic control and mechanical, fuel common rail system for customers to choose, we provide full life cycle service for all customers, from design to ship power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from Troubleshooting to Overhaul Technical Support.

Advantages of 3508 Fire Pump Engine

  • Package Size : Ultra-compact package size ensures ease of installation as well as exceptional power density.

  • Emissions : U.S. EPA Tier 3, Tier 2 or Non-certified emission standards for stationary emergency fire pump engines. FM Approved, UL Listed.

  • High Performance : Substantial torque rise delivers impressive performance throughout a wide speed range while maintaining lowoperating costs.

  •  Fuel Efficiency : Fuel consumption optimized to match operating cycles of a wide range of equipment and applications while maintaining low operating costs.

  • Reliable, Quiet and Durable Power : World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life.

Technical Specifications

Basic Introduction of Caterpillar 3508 Fire Pump Engine

Engine Model: 3508
Engine Type: V-8, 4-Stroke-Cycle Diesel
Displacement: 34.5 L
Rated Power / Speed: 746 kW @ 1800 RPM
Aspiration Method: Turbocharged Aftercooled (TA)
Emission Standard: Non-Certified
Bore * Stroke: 170 mm (6.7 in) * 190 mm (7.5 in)
Packing Size(L * W * H): 2136 mm * 1703 mm * 1720 mm
Weight , Net Dry: 4309 kg (9500 lb)
Lead Time: 15-30 Working Days
Payment Terms: T/T ,L/C

CAT C18-545 Land Driling Engine-788X376

coming soon

coming soon

Engine Model

Rated Power

Aspiration

Emissions

3508 746 kW  @ 1800 RPM Turbocharged-Aftercooled Non-Certified
—-END—-

General Engine Specifications of Caterpillar 3508 Pump Drive Engine

ENGINE Configuration V-8, 4-Stroke-Cycle-Diesel Emissions Non-Certified
Bore 170 mm (6.7 in) Stroke 190 mm (7.5 in)
Displacement 34.5 L (2107 in³) Aspiration Turbocharged-Aftercooled
Governor and Protection W3161 Oil Change Interval 500 hours
Length 2136 mm (84 in) Width 1703 mm (67 in)
Height 1720 mm (68 in) Weight 4309 kg (9500 lb)
Rotation Counterclockwise Flywheel Teeth 151 SAE 0
—-END—-

Engine Performance Data Rated Power of Caterpillar 3508 Pump Drive Engine

Maximum Power 746 bkW (1000 BHP) Rated Speed 1200 -1800 RPM
Minimum Power 507 bkW (680 BHP) Emissions Non-Certified
Aspiration Turbocharged Aftercooled (TA)
—-END—-

System of Caterpillar Caterpillar 3508 Pump Drive Engine

Control System Governor, RH, 3161 with Self Contained Synthetic Oil Sump Air Inlet System Aftercooler Core, Corrosion Resistant Coated (Air Side)
Air-Fuel Ratio Control Air Cleaner. Regular Duty, Dry, Panel Type with Service Indicators, Turbocharger, Jacket Water Aftercooled
Mechanical Speed Control, Without Torque Control Turbocharger, Rear Mounted
Governor Control Jacket Water Aftercooled
Positive Locking N/A
Cooling System Thermostats and Housing Fuel System Fuel Transfer Pump
Jacket Water Pump, Centrifugal Fuel Filter, with Service Indicators, Cartridge Type with RH Service
Lube System Crankcase Breather, Top Mounted Protection System Junction Box
Oil Cooler Manual Shutoff, RH
Oil Filler Safety Shutoff Protection, Energized to Shutdown
Oil Dipstick Low Oil Pressure, Low Idle 69 kPa (10 PSI); High Idle 207 kPa (30 PSI)
Oil Pump Water Temperature
Oil Filter, Cartridge Type with RH Service Overspeed
Shallow Oil Pan Governor Solenoid Energized to Shutdown
Fumes Disposal (Not Installed) N/A
Mounting System Rails, Mounting, Engine Length, 254 mm (10 in), Industrial-type, C-Channel Exhaust System Exhaust Manifold, Dry
Included on Selected Top Level Engines N/A
Instrumentation System Instrument Panel, RH
Engine Oil Pressure Gauge
Fuel Pressure Gauge
Oil Filter Differential Gauge
Jacket Water Temperature Gauge
Service Meter, Electric
Tachometer
—-END—-

Scopes of Supply of Caterpillar 3508 Pump Drive Engine

Air Intake System 1. Air Intake Manifold Exhuast System 1. Exhuast Manifold
2. Water-Air Intercooler 2. Turbocharger
3.Air Filter 3. Exhuast Elbow
Starting System 1. Starter Motor Charging System 1. Charging Alternator
2. Starter Rely 2. N/A
Lubricating System Fuel System
1. Electronic Fuel Transfer Pump
1. Oil Pump 2. Common Rail Fuel System
2. Oil Filter 3. Fuel Filter
4.ECU & Wiring Harness
Engine Auiliary Accessories 1.N/A Power Output System 1. Flywheel
2. N/A 2. Standard Flywheel Housing
Control System 1. ECU Socket and Sensors Engine Mounting System 1. Engine Mouting Bracket
Cooling System 1. Water Pump
2. Engine Fan
3. Standard Radiator
——END——

Optional Accessories of Caterpillar 3508 Pump Drive Engine

Air Intake System 1. Air Intake Pre-heater Exhuast System 1. Muffler & Bellows
2. Air Intake Pre-Filter 2. Flame Trap
3. Air Filter Alarm System 3. Spark Arrestor Type Muffler & Bellows
4. Air Intake Shut-Off Valve 4. DPF System
Fuel System 1. Coarse Filter Engine Auiliary Accessories 1. Hydraulic Oil Pump
2. Fuel Pre-Heater 2. Air Compressor
Starting System 1. Manual Magnetic DC Contactor Cooling System 1. Silent Type Radiator
2. Dual Ears Flywheel Housing 2. Plateau Radiator
3. Spring Starter Motor 3. Salt-Spray Resistant Radiator
4. Air Starter Motor 4. Coolant Pre-Heater
5. Hydraulic Starter Motor 5. Jacket Water Heater
6. Extra Electric Starter Motor 6. N/A
7. Remote Starting Function 7.N/A
8. Lock Protection Function of Starter Motor 8. N/A
9. Manual Magnetic DC Contactor 9. N/A
Power Output System 1. Clutch Control System 1. Engine Monitor
2. Add Gearbox for Higher Output Speed 2. NFPA20 Standard Engine Control Box
3. N/A 3. NFPA20 Fire Fighting Pump Set Control Panel
Lubricating System 1. Oil Pre-Heater Engine Mounting System 1. Shock Absorber Pad
——END——

As part of EMAC, PumpMac focusing on water pump set related business, from pump drive engine, to WPT PTO, from complete engine power pack to complete water pump set, from NFPA20 standard fire fighting pump accessories to fire pump drive package, from explosion proof accessories to complete explosion-proof water pump set, PumpMac provides professional one-stop solution for everything customer needed for water pump set industry.
For more information of our pump drive power pack and complete water pump set products, you are welcome to visit PumpMac homepage: www.pumpmac.com

Modifiable Components of CAT 3508 Pump Drive Engine

Air Intake System 1. Installation Position of Air Filter Charging System 1. 12V Charging Alternator for 12V Electric System
2. Upgrade to Heavy-Duty Type Air Fitler 2. Explosion-Proof Charging Alternator
 3.N/A 3. Upgrading to Specified Brand and Speicifications of Charging Alternator
Exhuast System 1. Can Modify Installation Position and Direction of Turbocharger Lubricating System 1. Oil Pan Position
2. Water-Cooled Exhuast Manifold 2. Number of Dipstick
3. Water-Cooled Turbocharger 3. Position of Dipstick Can Choose From 6 Positions
4. N/A 4. Can Modify Oil Filter to Be Remote Installation
Fuel System 1. Upgrade to Fuel Fitler That Integrated with Fuel Transfer Pump and Fuel Pre-Hearter Starting System 1. 12V starter motor for 12v electric system
2. N/A 2. Upgrading to Specified Brand and Speicifications of Starter Motor
Cooling System 1. Can Modify Engine Fan Into Blower Fan or Suction Fan Power Output System 1. Can Modify Size of Flywheel Housing and Flywheel
2. Can Modify Central Position of Engine Cooling Fan 2. Dual-Ear Flywheel Housing (for Twin-Starter System)
3. Can Choose Type of Engine Fan From Mechanical Type or Electric Type 3. Some of Models Can Modify Flywheel Housing Into Pto Integrated Type
4. Can Modify Cooling System Into Heat Exchanger and Intercooler 4. Engine Have Connecting Port of Ptos, That Able to Provide Power Output
Engine Shut-Down System 1. 12V Solenoid for 12V Electric System Engine Mounting System 1. Can Modify Engine Mouting Bracket
2. Explosion-Proof Solenoid
Engine Auiliary Accessories 1.N/A Control System 1. ECU Can Setting to Different Control Mode, Including Can  Communication, Analogu Control, Isc1,Isc2,Isc3 Speed Conrol Mode ETC
——END——

Note: All Above Data are Just for Referenece, All Data Might Change Without Notices or Update, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.

The picture of Sale Manual showing the accessories and scopes of supply.

Engine Sale Manual

The picture of Installation Drawing showing the accessories and scopes of supply.

Installation Drawing

The picture of Installation Manual showing the accessories and scopes of supply.

Installation Manual

The picture of Operation Manual showing the accessories and scopes of supply.

Operation Manual

The picture of Engine Parts Catalogue showing the accessories and scopes of supply.

Parts Catalogue

The picture of Test Report and Certifcate showing the accessories and scopes of supply.

Report & Certifcate
