Caterpillar C18 Series UL-listed Fire Pump Engine
The Caterpillar C18 Series UL-listed Fire Pump Engine is an I-6, 4-Stroke-Cycle-Diesel engine with a 183.0 mm (7.2 in) bore, 145.0 mm (5.7 in) stroke and 18.1 L (1104.5 in³) displacement.
Caterpillar® C18 Pump Engines, with ratings : 447 – 597 bkW (600 – 800 BHP) @ 1750-2100 RPM, meet U.S. EPA Tier 3 or U.S. EPA Tier 2 emission standards for stationary emergency pump engines. Rating: 522 bkW (700 BHP) @ 1500 RPM is Non-certified. All ratings are FM Approved and UL Listed. Starting on demand is a must for a pump engine – always. Caterpillar® pump engines have a reputation for reliable starts and long efficient service. The Caterpillar line of fire engine pumps covers a wide range of installations. At 447-597 bkW (600-800 BHP) the C18 is the newest addition to the Caterpillar pump engine line and continues the strong legacy of dependable starts and long, durable life.
As a partner of Caterpillar pump engine for many years, EMAC is a professional power system solution provider. We provide global customers with one-stop power system-sales solutions from power system design to power system supply, from installation to commissioning, and from after-sales. Program. With sales service support for spare parts supply, EMAC is your reliable powertrain partner, offering you the best cost-effective and reliable system solutions.
General Specifications of C18 Series
| Engine Type: | Inline 6, 4-Stroke-Cycle Diesel |
| Displacement: | 18.1 L |
| Rated Speed: | 447-597 kW @ 1750-2100 RPM |
| Emission Standards: | Tier 3 |
| Aspiration Method: | Turbocharged Aftercooled (TA) |
| Advertised Power: | 1500-2100 RPM |
| Peak Torque: | N/A |
| Bore * Storke: | 145 mm * 183 mm |
| Wet Weight: | 1953 kg (4306 lb) |
| Dimension(L * W * H): | 1889 mm * 1082 mm * 1380 mm |
Engine Model |
Rated Power |
Aspiration |
Engine Model |
Rated Power |
Aspiration |
||
| C18 | 447-597 kW @ 1750-2100 RPM | Turbocharged-Aftercooled | |||||
| ——END—— | |||||||
Caterpillar C18 Series UL-listed Fire Pump Engine
This list including all models of Caterpillar C18 Series Fire Pump Engine.
Click here to find Fire Pump engines by type (Fuel System & Engine Speed).
Caterpillar C18 Fire Pump Engine
Rated Power : 447-597 kW (600-800 BHP)
Engine Type : Inline 6, 4-Stroke-Cycle-Diesel
Bore x Strock : 145 mm(5.7 in) x 183 mm(7.2 in)
Displacement : 18.1 L (1104.5 in³)
Emission Standard : U.S. EPA Tier 3
