Caterpillar C18 Fire Pump Engine

The Caterpillar C18 UL-listed fire pump engine is an I-6, 4-Stroke-Cycle-Diesel engine with a 145.0 mm (5.7 in) bore, 183.0 mm (7.2 in) stroke and 18.1 L (1104.5 in³) displacement.

The Caterpillar C18 UL-listed fire pump engine is rated at 2100 RPM and rated at 800 BHP (597 bkW).

Caterpillar C18 UL-listed fire pump engine complies with U.S. EPA Tier 3, Tier 2 or Non-certified emission standards for stationary emergency pump engines.FM Approved, UL Listed, air intake is turbocharged After cooling.

As part of EMAC, Caterpillar Pump also offers high performance propulsion and handling solutions Engine, engine provides electronic control and mechanical, fuel common rail system for customers to choose, we provide full life cycle service for all customers, from design to ship power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from Troubleshooting to Overhaul Technical Support.

Advantages of C18 UL-listed Fire Pump Engine

Package Size : Ultra-compact package size ensures ease of installation as well as exceptional power density.
Emissions : U.S. EPA Tier 3, Tier 2 or Non-certified emission standards for stationary emergency pump engines. FM Approved, UL Listed.
High Performance : Substantial torque rise delivers impressive performance throughout a wide speed range while maintaining lowoperating costs.
Fuel Efficiency : Fuel consumption optimized to match operating cycles of a wide range of equipment and applications while maintaining low operating costs.
Reliable, Quiet and Durable Power : World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life.

Technical Specifications

Basic Introduction of Caterpillar C18 UL-listed Fire Pump Engine

Engine Model:	C18
Engine Type:	Inline 6, 4-Stroke-Cycle Diesel
Displacement:	18.1 L
Rated Power / Speed:	447-597 kW @ 1750-2100 RPM
Aspiration Method:	Turbocharged Aftercooled (TA)
Emission Standard:	Tier 3
*Bore Stroke:**	145 mm (5.7 in) * 183 mm (7.2 in)
*Packing Size(L W * H):**	1889 mm * 1082 mm * 1380 mm
Weight , Net Dry:	1953 kg (4306 lb)
Lead Time:	15-30 Working Days
Payment Terms:	T/T ,L/C

Coming Soon

coming soon

Engine Model	Rated Power	Aspiration	Emissions
C18	447-597 kW @ 1750-2100 RPM	Turbocharged-Aftercooled	U.S. EPA Tier 3, FM Approved, UL Listed
—-END—-

General Engine Specifications of CAT UL-listed Fire Pump Engine
ENGINE Configuration	Inline 6, 4-Stroke-Cycle-Diesel	Emissions	Tier 3
Bore	145 mm (5.7 in)	Stroke	183 mm (7.2 in)
Displacement	18.1 L (1104.5 in³)	Aspiration	Turbocharged-Aftercooled
Governor and Protection	Electronic ADEM™ A4	Oil Change Interval	250 – 500 hours
Length	1889 mm (74.7 in)	Width	1082 mm (42.6 in)
Height	1380 mm (54.3 in)	Weight	1953 kg (4306 lb)
Rotation	Counterclockwise	Flywheel Teeth	136 SAE 0
—-END—-

Engine Performance Data Rated Power of CAT UL-listed Fire Pump Engine
Maximum Power	597 kW (800 BHP)	Rated Speed	1500-2100 RPM
Minimum Power	447 kW (600 BHP)	Emissions	U.S. EPA Tier 3, FM Approved, UL Listed
Aspiration	Turbocharged Aftercooled (TA)
—-END—-

System of CAT C18 UL-listed Fire Pump Engine
Air Inlet System	Dual Turbocharger: Front and Rear Inlet 127 mm (5.0 in)	Exhaust System	Exhaust Manifold, Dry
	Separate Circuit Aftercooled (SCAC)		Dual Turbo: Exhaust Elbow, Dry 203 mm (8 in)
	Optional Air Cleaner – Dual Element, Installed		N/A
Charging System	Charging Alternator 24 Volt, 50 Amp	Mounting System	Front and Rear Support
Cooling System	Thermostats and Housing, Vertical Outlet	Fuel System	Electronic Unit Injector
	Jacket Water Pump, Gear Driven, Centrifugal		Fuel Filter, Secondary (2 Micron)
	Heat Exchanger Installed		Fuel Transfer Pump
	Expansion Tank		Fuel Sample Valve, Mounted on Fuel Filter Base
	N/A		Primary Fuel Filter / Water Separator
Control System	Dual Electronic Control Units (ECU), Primary and Secondary with Auto Switching Capability	Lube System	Crankcase Breather, Front Valve Cover
	Electronic Governing, PTO Speed Control		Oil Cooler
	Cold Mode Start Strategy		Lube Oil Filter
	Automatic Altitude Compensation		Front Sump Oil Pan
	Power Compensation for Fuel Temperature		Oil Filler
	Programmable Low and High Idle and Top Engine Limit		Oil Dipstick
	Electronic Diagnostics and Fault Logging		Oil Pump
	Engine Monitoring and Protection System (Speeds, Temperature, Pressure)		N/A
	Sae J1939 Broadcast (Diagnostic, Engine Status, and Control)		N/A
—-END—-

Scopes of Supply of CAT C18 UL-listed Fire Pump Engine
Air Intake System	1. Air Intake Manifold	Exhuast System	1. Exhuast Manifold
	2. Water-Air Intercooler		2. Turbocharger
	3.Air Filter		3. Exhuast Elbow

Starting System	1. Starter Motor	Charging System	1. Charging Alternator
Starting System	2. Starter Rely	Charging System	2. N/A
Lubricating System		Fuel System
			1. Electronic Fuel Transfer Pump
	1. Oil Pump		2. Common Rail Fuel System
	2. Oil Filter		3. Fuel Filter
			4.ECU & Wiring Harness

Engine Auiliary Accessories	1.N/A	Power Output System	1. Flywheel
Engine Auiliary Accessories	2. N/A	Power Output System	2. Standard Flywheel Housing

Control System	1. ECU Socket and Sensors	Engine Mounting System	1. Engine Mouting Bracket

Cooling System	1. Water Pump
	2. Engine Fan
	3. Standard Radiator
——END——

Optional Accessories of CAT C18 UL-listed Fire Pump Engine
Air Intake System	1. Air Intake Pre-heater	Exhuast System	1. Muffler & Bellows
	2. Air Intake Pre-Filter		2. Flame Trap
	3. Air Filter Alarm System		3. Spark Arrestor Type Muffler & Bellows
	4. Air Intake Shut-Off Valve		4. DPF System
Fuel System	1. Coarse Filter	Engine Auiliary Accessories	1. Hydraulic Oil Pump
Fuel System	2. Fuel Pre-Heater	Engine Auiliary Accessories	2. Air Compressor
Starting System	1. Manual Magnetic DC Contactor	Cooling System	1. Silent Type Radiator
	2. Dual Ears Flywheel Housing		2. Plateau Radiator
	3. Spring Starter Motor		3. Salt-Spray Resistant Radiator
	4. Air Starter Motor		4. Coolant Pre-Heater
	5. Hydraulic Starter Motor		5. Jacket Water Heater
	6. Extra Electric Starter Motor		6.N/A
	7. Remote Starting Function		7.N/A
	8. Lock Protection Function of Starter Motor		8.N/A
	9. Manual Magnetic DC Contactor		9.N/A
Power Output System	1. Clutch	Control System	1. Engine Monitor
	2. Add Gearbox for Higher Output Speed		2. NFPA20 Standard Engine Control Box
	3. N/A		3. NFPA20 Fire Fighting Pump Set Control Panel
Lubricating System	1. Oil Pre-Heater	Engine Mounting System	1. Shock Absorber Pad
——END——

As part of EMAC, PumpMac focusing on water pump set related business, from pump drive engine, to WPT PTO, from complete engine power pack to complete water pump set, from NFPA20 standard fire fighting pump accessories to fire pump drive package, from explosion proof accessories to complete explosion-proof water pump set, PumpMac provides professional one-stop solution for everything customer needed for water pump set industry.
For more information of our pump drive power pack and complete water pump set products, you are welcome to visit PumpMac homepage: www.pumpmac.com

Modifiable Components of CAT C18 UL-listed Fire Pump Engine
Air Intake System	1. Installation Position of Air Filter	Charging System	1. 12V Charging Alternator for 12V Electric System
	2. Upgrade to Heavy-Duty Type Air Fitler		2. Explosion-Proof Charging Alternator
	3.N/A		3. Upgrading to Specified Brand and Speicifications of Charging Alternator
Exhuast System	1. Can Modify Installation Position and Direction of Turbocharger	Lubricating System	1. Oil Pan Position
	2. Water-Cooled Exhuast Manifold		2. Number of Dipstick
	3. Water-Cooled Turbocharger		3. Position of Dipstick Can Choose From 6 Positions
	4. N/A		4. Can Modify Oil Filter to Be Remote Installation
Fuel System	1. Upgrade to Fuel Fitler That Integrated with Fuel Transfer Pump and Fuel Pre-Hearter	Starting System	1. 12V starter motor for 12v electric system
	2. N/A		2. Upgrading to Specified Brand and Speicifications of Starter Motor
Cooling System	1. Can Modify Engine Fan Into Blower Fan or Suction Fan	Power Output System	1. Can Modify Size of Flywheel Housing and Flywheel
	2. Can Modify Central Position of Engine Cooling Fan		2. Dual-Ear Flywheel Housing (for Twin-Starter System)
	3. Can Choose Type of Engine Fan From Mechanical Type or Electric Type		3. Some of Models Can Modify Flywheel Housing Into Pto Integrated Type
	4. Can Modify Cooling System Into Heat Exchanger and Intercooler		4. Engine Have Connecting Port of Ptos, That Able to Provide Power Output
Engine Shut-Down System	1. 12V Solenoid for 12V Electric System	Engine Mounting System	1. Can Modify Engine Mouting Bracket
	2. Explosion-Proof Solenoid
Engine Auiliary Accessories	1.N/A	Control System	1. ECU Can Setting to Different Control Mode, Including Can Communication, Analogu Control, Isc1,Isc2,Isc3 Speed Conrol Mode ETC
