YQFD-4102AHM Series UL-listed Fire Pump Engine
The YQFD-4102AHM Series UL-listed Fire Pump Engine is an In-Line 4 Cylinder 4 Cycle Diesel Engine with a 102 mm bore, 118 mm stroke and 3.857 L displacement.
YQFD-4102AHM Pump Engines, with ratings : 0.41 kW – 84 kW (0.55 – 112.66 HP) @ 500 – 2950 RPM, meet U.S. EPA Tier 3 or U.S. EPA Tier 2 emission standards for stationary emergency pump engines. Rating: 77 kW (103.26 HP) @ 2950 RPM. All ratings are FM Approved and UL Listed. Starting on demand is a must for a pump engine – always. YQFD-4102AHM adopts a turbocharged air intake method, with strong power output and stable power performance at different speeds, which can meet the power demands of various working conditions. For example, at 2950 RPM, the power can reach 84 kW (112.66 HP), providing sufficient power for the equipment.
As a partner of YuanQuan pump engine for many years, EMAC is a professional power system solution provider. We provide global customers with one-stop power system-sales solutions from power system design to power system supply, from installation to commissioning, and from after-sales. Program. With sales service support for spare parts supply, EMAC is your reliable powertrain partner, offering you the best cost-effective and reliable system solutions.
General Specifications of YQFD-4102AHM Series
| Engine Type: | In-Line 4 Cylinder 4 Cycle Diesel Engine |
| Displacement: | 3.857 L |
| Power: | 77 kW (103.26 HP) |
| Emission Standards: | N/A |
| Rated Speed: | 77 kW @ 2950 RPM |
| Aspiration Method: | Turbocharged (T) |
| Advertised Power: | 500-2950 RPM |
| Compression Ratio: | 17 :1 |
| Bore * Storke: | 102 mm * 118 mm |
| Wet Weight: | 500 kg (1102.31 lb) |
Engine Model |
Rated Power |
Aspiration |
Engine Model |
Rated Power |
Aspiration |
||
| YQFD-4102AHM | 77 kW @ 2950 RPM | Turbocharged | |||||
| ——END—— | |||||||
YQFD-4102AHM Series UL-listed Fire Pump Engine
This list including all models of YQFD-4102AHM Series Fire Pump Engine.
Click here to find Fire Pump engines by type (Fuel System & Engine Speed).
YQFD-4102AHM Fire Pump Engine
Rated Power: 77 kW (103.26 HP) @ 2950 RPM
Fuel System: Direct Injection in Cylinder
Compression Ratio: 17.0 : 1
Aspiration: Turbocharged
Emission Standard: N/A
