PumpMac YQFD-610X Series Fire Pump Engine
PumpMac YQFD-610X Series Fire Pump Engine is a 4-cylinder inline, 4 liters four-strokes engine with 108 mm bore and 115 mm stroke. YQFD-610X Series Fire Pump Engine equipped with PT Fuel System, comes with turbocharger. The power of PumpMac YQFD-610X Series fire pump engine is from 120.69 HP (90 kW). The speed of the YQFD-610X Series fire pump engine is 2950 RPM.
EMAC is a partner of PumpMac for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
General Specifications of YQFD-610X Series
| Engine Type: | 4 Cycle , 6 Cylinder |
| Displacement: | 6.5-6.87 L |
| Rated Speed: | N/A |
| Rated Power / Speed: | 140 – 250 kW @ 1470 – 2950 RPM |
| Compres Sion Ration: | 16:1 – 17.5:1 |
| Electrical System: | 24 V |
| Air Intake Mode: | Turbocharge |
| Bore * Stroke: | 105-108 mm * 124-125 mm |
| Basic Engine (L * W * H): | N/A |
| Cooling System Design: | Super Charged Inter Cooling |
Engine Model |
Power |
Speed |
Engine Model |
Power |
Speed |
|
| YQFD-6105AHM | 140-155 kW (87.74-207.86 HP ) | 1470-2100 RPM | YQFD-6108AHM | 250 kW (335.26 HP) | 2950 RPM | ——END—— |
PumpMac YQFE-610X Series Fire Pump Engine
This list including all models of PumpMac YQFE-610X Series Fire Pump Engine.
Click here to find fire pump engines by type (Fuel System & Engine Speed).
YQFD-6105AHM Fire Pump Engine
Power: 140/152/155 kW
Speed: 1470/1760/2100 RPM
Compression Ratio: 16 : 1
Aspiration: Supercharged Intercooling
Emission Standard: N/A
YQFD-6108AHM Fire Pump Engine
Power: 250 kW (335.26 HP)
Speed: 2950 RPM
Compression Ratio: 17.5 : 1
Aspiration: Supercharged Intercooling
Emission Standard: N/A
