YQFD-6135AHM Fire Pump Engine
YQFD-YQFD-6135AHM Fire Pump Engine is a 6-cylinders in line, 12.88 liters four-strokes engine with 135 mm bore and 150 mm stroke. Equipped with mechanical fuel pump and electronic governor, comes with supercharged intercooling.The prime power at 1470/1760 RPM of YQFD-6135AHM Fire Pump Engine is 255/280 kW.As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc.We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of YQFD-6135AHM Fire Pump Engine
-
Thrives in -20°C to 90°C temperatures and corrosive/abrasive media (slurries, chemicals, saltwater) . The reinforced 316L stainless steel casing and diamond-like carbon (DLC) coated shaft resist wear, ensuring 10,000+ hours of maintenance-free operation.
-
Balances exceptional high head (up to 18 Bar) and large flow rate (25m³/h) —a rare combo in its class. Handles both high-pressure transfer and bulk fluid movement, eliminating the need for multiple pumps in mixed-requirement setups.
-
Integrates predictive maintenance sensors that monitor bearing temperature, seal integrity, and motor load. Sends real-time alerts via IoT platforms, preventing unexpected downtime and reducing repair costs by 40%.
-
Uses lead-free materials and low-VOC lubricants, meeting global environmental standards (RoHS, REACH) . Energy efficiency exceeds IE5 classification, qualifying for green building and industrial sustainability incentives.
-
Comes with a intuitive touchscreen control panel (no complex programming required) and self-diagnostic functions. Runs at <62dB—quieter than a desktop fan—with anti-vibration feet that protect flooring and nearby equipment.
Technical Specifications
| Engine Model: | YQFD-6135AHM |
| Engine Type: | 6 Cylinders, in Line |
| Displacement: | 12.88 L |
| Rated Speed: | 1470/1760 RPM |
| Power: | 255/280 kW |
| Speed Regulation: | Mechanical Speed Regulation |
| Combustion Ration: | 15.75:1 |
| Aspiration Method: | Supercharged Intercooling |
| Electrical System: | 24 V |
| Filter Type: | Dry Detachable Air Filter |
| Bore*stroke: | 135*150 mm |
| Dry Weight: | 1542 kg |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T ,L/C |
Engine Model |
Output Power |
Torque |
Combustion System |
Aspiration |
| YQFD-6135AHM | 255 kW @ 1470 RPM 280 kW @ 1760 RPM | 341.9 HP @ 1470 RPM 375.5 HP @ 1760 RPM | Direct Injection in Cylinder | Supercharged Intercooling |
| ——END—— | ||||
General Infomation of YQFD-6135AHM Fire Pump Engine |
|||
| Engine Model | YQFD-6135AHM | Output Power | 341.9 HP @ 1470 RPM 375.5 HP @ 1760 RPM |
| Torque | 341.9 HP @ 1470 RPM 375.5 HP @ 1760 RPM |
No. of Cylinders | 6 Cylinders |
| Compression Ratio | 15.75 : 1 | Aspiration | Supercharged Intercooling |
| Cooling System | Positive Water Cooling Cycle | Emission Certification | N/A |
| Displacement | 15.75 L | Bore * stroke | 135 mm * 150 mm |
| Governor Regulation | ≤ 10% | Application | Water Pump |
| Dry Weight | 1542 kg | CPL Code Revision | N/A |
| Basic Engine(L * W * H) | N/A | ||
| ——END—— | |||
Coming Soon
Coming Soon
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
