PumpMac YQFD-613X Series Fire Pump Engine
PumpMac YQFD-613X Series Fire Pump Engine is a 6-cylinder inline, 4 liters four-strokes engine with 135 mm bore and 150 mm stroke. YQFD-613X Series Fire Pump Engine equipped comes with Supercharged Intercooling. The power of PumpMac YQFD-613X Series fire pump engine is from 341.9/375.5 HP (255/280 kW). The speed of the YQFD-613X Series fire pump engine is 1470/1760 RPM.
EMAC is a partner of PumpMac for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
General Specifications of YQFD-613X Series
| Engine Type: | 4 Cycle , 6 Cylinder |
| Displacement: | 12.88 L |
| Rated Speed: | N/A |
| Rated Power / Speed: | 255/280 kW @ 1470/1760 RPM |
| Compres Sion Ration: | 15.75:1 |
| Electrical System: | 24 V |
| Air Intake Mode: | Supercharged Intercooling |
| Bore * Stroke: | 135 mm * 150 mm |
| Basic Engine (L * W * H): | N/A |
| Cooling System Design: | Positive Water Cooling Cycle |
Engine Model |
Power |
Speed |
Engine Model |
Power |
Speed |
|
| YQFD-6135AHM | 255/280 kW (341.9/375.5 HP ) | 1470/1760 RPM | ||||
| ——END—— | ||||||
PumpMac YQFE-613X Series Fire Pump Engine
This list including all models of PumpMac YQFE-613X Series Fire Pump Engine.
Click here to find fire pump engines by type (Fuel System & Engine Speed).
YQFD-6135AHM Fire Pump Engine
Power: 255/280 kW (341.9/375.5 HP)
Speed: 1470/1760 RPM
Compression Ratio: 15.75 : 1
Aspiration: Supercharged Intercooling
Emission Standard: N/A
