YQFD-6105AHM Fire Pump Engine

YQFD-YQFD-6105AHM Fire Pump Engine is a 6-cylinders in line, 6.5 liters four-strokes engine with 105 mm bore and 124 mm stroke. Equipped with mechanical fuel pump and electronic governor, comes with supercharged intercooling.

The prime power at 1470/1760/2100 RPM of YQFD-6105AHM Fire Pump Engine is 140/152/155 kW.

As part of EMAC, PumpMac provides abundant premium pump-driven power pack options, WPT PTO, Advance gearbox and pump head, as well as customized water pump set. We also have a set of NFPA20 standard engine power pack accessories including air intake shut-off valve, DC contactor, engine control panel, jacket water heater etc.

We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.

Advantages of YQFD-6105AHM Fire Pump Engine

The YQFD-6105AHM features an advanced permanent magnet motor design that delivers energy savings of up to 70% compared to traditional pumps . Its high-efficiency impeller design and optimized hydraulic performance ensure minimal power consumption while maintaining maximum output, making it ideal for energy-conscious applications.
With a space-saving vertical structure and significantly reduced weight (up to 80% lighter than conventional pumps) , this pump offers effortless installation and portability. The compact design allows for easy integration into tight spaces without compromising performance.
Constructed with premium-grade 304 stainless steel for the pump body and wear-resistant ceramic shaft core , the YQFD-6105AHM withstands harsh operating conditions and extends service life. The double-seal tungsten carbide-tungsten carbide design provides reliable protection against water ingress.
The dual-bearing support structure and precision-balanced impeller minimize vibration and noise levels, ensuring quiet operation (<75dB) . This stability not only enhances user experience but also significantly reduces maintenance requirements and extends equipment lifespan.
The design eliminates the need for priming before operation and features tool-free access to key components for simplified maintenance. Its plug-and-play functionality reduces installation time and operational complexity, even for non-technical users, while minimizing downtime during servicing

Technical Specifications

Engine Model:	YQFD-6105AHM
Engine Type:	6 Cylinders, in Line
Displacement:	6.5 L
Rated Speed:	1470/1760/2100 RPM
Power:	140/152/155 kW
Speed Regulation:	Mechanical Speed Regulation
Combustion Ration:	16:1
Aspiration Method:	Supercharged Intercooling
Electrical System:	24 V
Filter Type:	Dry Detachable Air Filter
*Borestroke:**	105*124 mm
Dry Weight:	864 kg
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T ,L/C

Engine Model	Output Power	Torque	Combustion System	Aspiration
YQFD-6105AHM	140 kW @ 1470 RPM /152 kW@1760 RPM /155 kW@2100 RPM	187.74 N.m @ 1470 RPM 203.84 N.m @ 1760 RPM 207.86 N.m @ 2100 RPM	Direct Injection in Cylinder	Supercharged Intercooling
YQFD-6108AHM	250 kW@2950 RPM	335.26 HP @ 2950 RPM	Direct Injection in Cylinder	Supercharged Intercooling
——END——

General Infomation of YQFD-6105AHM Fire Pump Engine
Engine Model	YQFD-6105AHM	Output Power	140 kW@ 1470RPM /152 kW@1760RPM /155 kW@2100RPM
Torque	187.74 N.m @ 1470 RPM 203.84 N.m @ 1760 RPM 207.86 N.m @ 2100 RPM	No. of Cylinders	6 Cylinders
Compression Ratio	16 : 1	Aspiration	Supercharged Intercooling
Cooling System	Water Cooling Cycle	Emission Certification	N/A
Displacement	6.5 L	*Bore stroke**	105 mm * 124 mm
Governor Regulation	≤ 10%	Application	Water Pump
Dry Weight	864 kg	CPL Code Revision	N/A
*Basic Engine(L W * H)**	N/A
