C18 Series UL-listed Fire Pump Engine
The C18 Series UL-listed Fire Pump Engine is an I-6, 4-Stroke-Cycle-Diesel engine with a 183.0 mm (7.2 in) bore, 145.0 mm (5.7 in) stroke and 18.1 L (1104.5 in³) displacement.C18 Pump Engines, with ratings: 447 – 597 bkW (600 – 800 BHP) @ 1750-2100 RPM, meet U.S. EPA Tier 3 or U.S. EPA Tier 2 emission standards for stationary emergency pump engines. The rating of 522 bkW (700 BHP) @ 1500 RPM is Non-certified. All ratings are FM Approved and UL Listed. Reliable on-demand starting is an essential requirement for any pump engine. These pump engines are renowned for dependable starts and long efficient service life. This line of fire pump engines suits a wide range of installation conditions. Delivering 447-597 bkW (600-800 BHP), the C18 is the newest addition to the pump engine lineup, inheriting the consistent strengths of reliable startup and excellent durability.Having served pump engine solutions for many years, EMAC is a professional power system solution provider. We offer global customers one-stop power system services, covering power system design and supply, installation and commissioning, as well as after-sales support and spare parts supply. As your reliable powertrain partner, we deliver cost-effective and stable system solutions.
General Specifications of C18 Series
| Engine Type: | Inline 6, 4-Stroke-Cycle Diesel |
| Displacement: | 18.1 L |
| Rated Speed: | 447-597 kW @ 1750-2100 RPM |
| Emission Standards: | Tier 3 |
| Aspiration Method: | Turbocharged Aftercooled (TA) |
| Advertised Power: | 1500-2100 RPM |
| Peak Torque: | N/A |
| Bore * Storke: | 145 mm * 183 mm |
| Wet Weight: | 1953 kg (4306 lb) |
| Dimension(L * W * H): | 1889 mm * 1082 mm * 1380 mm |
Engine Model |
Rated Power |
Aspiration |
Engine Model |
Rated Power |
Aspiration |
||
| C18 | 447-597 kW @ 1750-2100 RPM | Turbocharged-Aftercooled | |||||
| ——END—— | |||||||
C18 Series UL-listed Fire Pump Engine
This list including all models of C18 Series Fire Pump Engine.
Click here to find Fire Pump engines by type (Fuel System & Engine Speed).
C18 Fire Pump Engine
Rated Power : 447-597 kW (600-800 BHP)
Engine Type : Inline 6, 4-Stroke-Cycle-Diesel
Bore x Strock : 145 mm(5.7 in) x 183 mm(7.2 in)
Displacement : 18.1 L (1104.5 in³)
Emission Standard : U.S. EPA Tier 3
