CCEC KTA50 Fire-fighting Pump Engine
CCEC K50 Series Fire-fighting Pump Engine is V type 16-cylinder, 50.3 liters four-strokes engine with 159 mm (6.25 in) bore and 159 mm (6.25 in) stroke. K50 Series Fire-fighting Pump equipped with CMS PT Fuel System, comes with turbocharger, and provide Low Temperature Aftercooled and Air-Air intercooler for customers to choose. The power range of CCEC K50 series Fire-fighting Pump is from 1645 HP to 2000 HP (1227 kW to 1491 kW). The torque range of the K50 Series Pump Drive Engine is 5544 N.m to 8790 N.m.
EMAC is a partner of CCEC for many years, we are a professional pump system solution supplier with many years of experience. We provide customers from all over the world with one-stop pump system solutions from pump system design to pump system supply, from installation to commissioning, and from after-sales. Providing sales service support for spare parts supply, EMAC is your reliable pump system partner, providing you with the best value for money and reliable system solutions.
General Specifications of KTA50 Series
| Engine Type: | 4 Cycle , 60° Vee , 16 Cylinder Diesel |
| Displacement: | 50 L |
| Rated Speed: | 1800 – 1900 RPM |
| Rated Power / Speed: | 1227 – 1657 kW @ 1800 – 1900 RPM |
| Peak Torque: | 5544 – 8790 N.M @ 1800 – 1900 RPM |
| Fuel System: | CMI PT / Cummins PT |
| Aspiration Method: | Turbocharged & Water-Air Intercooler |
| Bore * Stroke: | 159 mm * 159 mm |
| Basic Engine (L * W * H): | 2857 mm * 1415 mm * 1766 mm |
| Wet Weight: | 5662 kg |
Engine Model |
Rated Power |
Peak Torque |
Engine Model |
Rated Power |
Peak Torque |
|
| KTA50-P1645 | 1227 kW (1645 HP) @ 1800 RPM | 6100 N.m @ 1800 RPM | KTA50-P1915 | 1429 kW (1915 HP) @ 1800 RPM | 5544 N.m @ 1800 RPM | |
| KTA50-P2220 | 1657 kW (2220 HP) @ 1800 RPM | 8790 N.m @ 1800 RPM | KTTA50-2000 | 1491 kW (2000 HP) @ 1900 RPM | 7498 N.m @ 1900 RPM | |
| ——END—— | ||||||
CCEC KTA50 Series Pump Engine
This list including all models of CCEC KTA50 Series Pump Engine.
Click here to find pump engines by type (Fuel System & Engine Speed).
CCEC KTA50-P1645 Pump Engine
Rated Power: 1227 kW (1645 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 13.9 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
CCEC KTA50-P1915 Pump Engine
Rated Power: 1429 kW (1915 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 14.9 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
CCEC KTA50-P2220 Pump Engine
Rated Power: 1657 kW (2220 HP) @ 1800 RPM
Fuel System: CMI PT
Compression Ratio: 13.9 : 1
Aspiration: TC & Water-Air Intercooler
Emission Standard: N/A
CCEC KTTA50-2000 Pump Engine
Rated Power: 1491 kW (2000 HP) @ 1900 RPM
Fuel System: CMI PT
Compression Ratio: 13.8 : 1
Aspiration: Dual TC and Low Temp. Aftercooled
Emission Standard: N/A
